Icons
A component definition also includes the symbol, which is used to represent instances of this definition.
For this purpose Pathfinder provides a symbol library containing more than 40 symbols:
![](../../../__attachments/3351216207/symbole_netzwerkdokumentation.png%3Fversion=1&modificationDate=1390400984728&api=v2?inst-v=f1245147-b616-4101-98c2-c12a7cc79779)
Pathfinder provides a symbol library containing more than 40 graphical representations of port types:
![](../../../__attachments/3351216207/porttypen_netzwerkdokumentation.png%3Fversion=1&modificationDate=1513849844806&cacheVersion=1&api=v2?inst-v=f1245147-b616-4101-98c2-c12a7cc79779)
